| Tonnage | 440 T | 399.162 t |
| Type | HYD | HYD |
| Overall Length | 253.94" | 6.5 m |
| Between Housings | 148.82" | 3.8 m |
| Stroke | 14.76" | 374.9 mm |
| # Axis | 6 | 6 |
| Control | CNC (Delem 66-T CNC Touch Control) | CNC (Delem 66-T CNC Touch Control) |
| Dimensions | 253.94"(L) x 106.69"(W) x 137.80"(H) | 253.94"(L) x 106.69"(W) x 137.80"(H) |
| Weight | 58,694.724 lbs | 58,694.724 lbs |
DELEM DA-66T, TOUCH SCREEN CNC CONTROLLER
TOTAL OF 6 AXIS (Y1, Y2, X, R,Z1, Z2) X:800 MM, R=250MM
ERMAKSAN FOUR AXIS BACKGAUGE (X, R, Z1, Z2)
AMERICAN PROMECAM QUICK RELEASE
ROLLERI TOP TOOL ROLLERI - 0813/011/11
M460-R 4 V BOTTOM TOOL
275 (10,8”) MM HIGH STROKE
410 (16”) MM THROAT DEPTH
460 VOLTAGE, 3PH, 60HZ
BACK SIDE SAFETY – LIGHT BARRIER
SIDE GUARDS WITH SWITCH
DOUBLE FOOT PEDAL CONTROLLER
HOERBIGER HYDRAULIC SYSTEM
SIEMENS ELECTRIC SYSTEM
SLIDING FRONT SUPPORT ARMS
STANDARD NARROW TABLE
RAL 7035, RAL 2008 COLORS
ENGLISH LABEL
ENGLISH MANUAL
