| Tonnage | 150 T | 136.078 t |
| Between Housings | 12' | 3.7 m |
| Stroke | 11" | 279.4 mm |
| # Axis | 6 | 6 |
| Control | CNC (Delem 66-T CNC Touch Control) | CNC (Delem 66-T CNC Touch Control) |
| Dimensions | 187 x 89 x 114 | 187 x 89 x 114 |
| Weight | 18047 | 18047 |
Spec Sheet Included in attached PDF
DELEM DA-66, TOUCH SCREEN CNC CONTROLLER
TOTAL OF 6 AXIS (Y1, Y2, X, R,Z1, Z2) X:800 MM, R=250MM
ERMAKSAN FOUR AXIS BACKGAUGE (X, R, Z1, Z2)
AMERICAN PROMECAM QUICK RELEASE
ROLLERI TOP TOOL ROLLERI - 0813/011/11
M460-R 4 V BOTTOM TOOL
275 (10,8”) MM HIGH STROKE
410 (16”) MM THROAT DEPTH
460 VOLTAGE, 3PH, 60HZ SINGLE VOLTAGE
LAZERSAFE LIGHT GUARD FOR FINGER PROTECTION
CNC CROWNING SYSTEM (ANTI-DEFLECTION)
BACK SIDE SAFETY – DOOR WITH SWITCH
SIDE GUARDS WITH SWITCH
DOUBLE FOOT PEDAL CONTROLLER
HOERBIGER SYSTEM
SIEMENS ELECTRIC SYSTEM
SLIDING FRONT SUPPORT ARMS
STANDARD TABLE
ENGLISH LABEL
ENGLISH MANUAL
