ERMAKSAN Falcon-Bend 20' x 350Ton w/ Delem 58T Controller

POWER BEND FALCON 20'-352

0

BENDING LENGTH ( A ) 240.16 "
MAX. POWER 352 US Tons
MAX.BENDING CAPACITY (59738 psi) 0.31 " V= 3.1 "
MAX.BENDING CAPACITY (73974 psi) 0.28 " V= 3.1 "
MAX.BENDING CAPACITY (81087 psi) 0.28 " V= 3.1 "
MAX.BENDING CAPACITY (89622 psi) 0.24 " V= 3.1 "
MAX.BENDING CAPACITY (99580 psi) 0.24 " V= 3.1 "
AXIS NUMBER OF MACHINE Y1,Y2,X,R -
FREE DOWN SPEED 3.15 in/s
BENDING SPEED 0.41 in/s
RETURN BACK SPEED 2.95 in/s
STROKE ( C ) ( Y1 , Y2 ) 14.76 "
BACK GAUGE STROKE ( X AXIS ) 31.50 "
BACK GAUGE STROKE ( R AXIS ) 9.84 "
DISTANCE BETWEEN HOUSING ( B ) 200.79 -
CROWNING MOTORIZED -
THROAT DEPTH ( E ) 16.14 "
TABLE HEIGHT ( F ) 43.31 "
TABLE WIDTH ( G ) 7.09 "
DAYLIGHT ( D ) 25.59 "
PLANT VOLTAGE 380 V
IP 54 -
MAIN MOTOR 40 HP
BACK GAUGE MOTORS (X,R) 2.4+4.78 Nm
PLANT TEMPERATURE 0-50 oC
MAX. NOISE 70 dB
OIL CAPACITY 105.68 US Gallons
MAX. PRESSURE 3697.2 psi
MACHINE LENGTH ( L ) 320.87 "
MACHINE WIDTH ( W ) 102.36 "
MACHINE HEIGHT ( H ) 140.35 "
WEIGHT 67001.6 lbs
