| Tonnage | 242 T | 219.539 t |
| Type | HYD | HYD |
| Overall Length | 168.11" | 4.3 m |
| Between Housings | 148.82" | 3.8 m |
| Stroke | 10.83" | 275.08 mm |
| # Axis | 6 | 6 |
| Control | CNC (Delem 66T) | CNC (Delem 66T) |
| Dimensions | 246.85" x 88.58" x 118.11" | 246.85" x 88.58" x 118.11" |
| Weight | 30856 lbs | 30856 lbs |
Delem 66T, TOUCH SCREEN CNC CONTROLLER 1
TOTAL OF 6 AXIS (Y1, Y2, X, R,Z1, Z2) X:800 MM, R=250MM 1
ERMAKSAN FOUR AXIS BACKGAUGE (X, R, Z1, Z2) 1
AMERICAN PROMECAM QUICK RELEASE 1
ROLLERI TOP TOOL ROLLERI - 0813/011/11 1
M460-R 4 V BOTTOM TOOL 1
275 (10,8”) MM HIGH STROKE 1
410 (16”) MM THROAT DEPTH 1
460 VOLTAGE, 3PH, 60HZ 1
BACK SIDE SAFETY – LIGHT BARRIER 1
SIDE GUARDS WITH SWITCH 1
DOUBLE FOOT PEDAL CONTROLLER 1
HOERBIGER HYDRAULIC SYSTEM 1
SIEMENS ELECTRIC SYSTEM 1
SLIDING FRONT SUPPORT ARMS 2
STANDARD NARROW TABLE 1
RAL 7035, RAL 2008 COLORS 1
ENGLISH LABEL 1
ENGLISH MANUAL 1
