AMADA VT7995S (800APC) VERTICAL TILT-FRAME SAW
Have one to sell?
ConditionNew
New
Worlds Largest Vertical Tilt-Frame
• 15 HP
• 2″ Blade
• Marvel Series (800APC)
• Automatic Indexing
• Heavy-Duty
• Hydraulic
• Metal Cutting
• High-Speed Bandsaw
• Programmable Control
• Servo Shuttle
• +/- 60 Degree Miter
FEATURES
• Tilting Column
- For miter cutting up to 60o left and right of vertical. Electronic tilt- The column is electrically powered, chain driven, with
encoder feedback and PC3 touch screen controller for precision miter positioning.
• 0° or 3° Canted Column
- Standard 3-degree forward canted head increases cutting efficiencies when cutting structural materials. An optional straight column for notching or cutting rounds and pipe.
• Blade Guide
- Rotating Easy Load Combination Carbide and Ball Bearing
Roller guides with self-tensioning design.
• Upper Blade Guide Arm
- Hydraulically positioned and locking, controlled by a selector switch at the operator’s station.
• Work-Rest Rollers
- Two turned ball-bearing rollers, one on the entry side and one on the discharge side of the machine bed.
• Vises
- Hydraulic, full stroking with 9-1/2” high x 15” wide 60° faceplates. Optional variable vise pressure available (Option Code M9A).
• PC3 Programmable Control®
- Provides a Programmable Logic Control Unit with a 12” color, touch screen display. The control features graphical part programming with memory for up to 500 jobs and parts, as well as a material selection chart and customizable material library.
Cutting Capacity Round (Diameter):
at 0° 31.25″ 794 mm
at 45° Right 25.5″ 648 mm
at 45° Left 24″ 610 mm
at 60° Right 17.5″ 444 mm
at 60° Left 15.75″ 400 mm
Rectangle (W x H)
at 0° 31.25″ x 37.5″ 794 x 952 mm
at 45° Right 31.25″ x 25.5″ 794 x 648 mm
at 45° Left 31.25″ x 24″ 794 x 610 mm
at 60° Right 31.25″ x 17.5″ 794 x 444 mm
at 60° Left 31.25″ x 15.75″ 794 x 400 mm
Maximum Vise Opening
31.25″ 794 mm
Work Load Capacity 5,000 lbs 2,268 kg
Saw Blade:
Dimensions (L x T x W) 25′ x 0.063″ x 2″ 7620 x 1.6 x 54 mm
Blade Speed 60-400 ft./min by Inverter 18-122 m/min by Inverter
Tension Control Hydraulic
Blade Control:
Cutting Control Direct Force Sensing Electric Ball Screw
with PC3 Programmable Control
Blade Feed Force 0 to 350 lbs 0 to 1556 N
Vise Operation:
Type Main Vise (Optional second vise is available to install)
Control Hydraulic, Full Stroking with 12″ High x 20″ Wide 60° Faceplates
Motors:
Saw Blade 15 HP 11.2 kW
Hydraulic Pump 5 HP 3.7 kW
Cutting Fluid Pump 1/2 HP 0.4 kW
Tilt Gear 1/15 HP 0.05 kW
Power Requirement:
Power Supply Voltage AC230V±10% or AC460V±10%, 3 PH, 60 Hz Voltage must be specified when ordering
Power Requirement
Cutting Fluid:
Tank Capacity 75.0 gal 284 liters
Pump Type Electric
Hydraulic
Tank Capacity 10 gal 38 liters
Chip Disposal
Manual
Standard Feed Vise:
Feed Mechanism Shuttle Vise
Material Index AC Servo Motor and Linear Guides
Feed Stroke 72″ 1829 mm
Remnant Length 23″ plus length of parts 584 mm plus length of parts
Machine Dimensions (W x L x H) 153.6″ x 191.8″ x 144.7″ 3901 x 4871 x 3674 mm
Table Height (Above Floor) 52.0″ 1321 mm
