| Control | CNC | CNC |
| Dimensions | 161.4" x 91.5" x 88" | 161.4" x 91.5" x 88" |
| Weight | 26,460 lbs | 26,460 lbs |
Cutting Length: 122"
Cutting Capacity: 0.51"
Cutting Angle: 2 degrees
Stroke Per Minute: 9
Back gauge Stroke: 39.37"
Number of Hold Downs: 14
Throat Depth: 13.78"
Table Height: 35.43"
Main Motor: 29.5 HP
Back Gauge Motor: 1.01 HP
IP: 54
Plant Voltage: 380 V
Max Noise: 70 dB
Oil Capacity: 81.9 US Gallons
Max Pressure 4060 PSI
Table Width: 23.6"
Ercut CNC
CNC Back gauge
CNC Blade Gap
Stainless Suitable Blade
Back light barrier
Table with ball transfer
Finger guard
Swing Beam Style
This equipment is currently unavailable. Similar equipment available now is shown below.
